Apc Smart-Ups Smt2200 (2200va) LCD 230v Ups

The APC Smart-UPS SMT2200 (2200VA) LCD 230V is a line-interactive power protection unit designed primarily for servers, networking equipment, and critical IT infrastructure. It provides clean network-grade power with a pure sine wave output, which is essential for equipment with active power factor corrected (PFC) power supplies.

Key Performance Specifications:
Power Capacity: 2200VA / 1980W.
Nominal Output/Input Voltage: 230V (configurable for 220V or 240V).
Efficiency: Over 97% in "Green Mode," which bypasses unused electrical components to reduce heat and energy costs.

Runtime Examples:
Full Load (1980W): Approximately 8.4 minutes.
Half Load (990W): Approximately 24.5 minutes.

Essential Features:
LCD Interface: A multifunction console that displays status indicators, battery life, and power usage. It allows for local configuration without needing a computer.
Automatic Voltage Regulation (AVR): Corrects high and low voltage conditions without switching to battery power, preserving battery life.
SmartSlot: A slot for adding management cards, such as a Network Management Card (NMC), for remote monitoring and graceful server shutdowns.
Connectivity: Includes USB and serial ports for local management, as well as a SmartConnect port for cloud-based remote monitoring on some models (e.g.,SmartConnect port for cloud-based remote monitoring on some models (e.g., SMT2200IC).
Battery Management: Features temperature-compensated charging and an intelligent system that predicts the battery replacement date.

Physical Connections & Dimensions:
Output Outlets: Typically includes 8x IEC 320 C13 and 1x (or 2x depending on model) IEC 320 C19 outlets.
Input: IEC 320 C20 connector.
Form Factors: Available in both Tower (SMT2200I/SMT2200IC) and Rackmount 2U (SMT2200RMI2U) versions.
